Material |
Coil-coated aluminium, 0.7 mm thick |
|---|---|
Size |
700×420 mm in installed area |
Weight |
1 m² = approx. 2.5 kg = 3.4 pcs. |
Roof pitch |
From 17° = approx. 31% |
Substructure and separation layer |
See chapter “General information”, a bituminous separation layer is required up to a roof pitch of 25°. |
Standard fastening |
Direct, 3 2.8/25 grooved nails per R.16 roof tile |
