Rhomboid façade tile 29 × 29

Give traditional façade design a new lease of life: Classic rhomboid façade tile with a matt, elegant structure.

+6
read more

The perfect combination of style and function: Façades covered with rhomboid façade tiles are characterised by harmonious light and shade effects – and are extremely robust. Alloys according to EN 1396 make up the basic material of PREFA aluminium products. The rhomboid façade tile 29 × 29 is coated in a coil-coating procedure and is subject to the strict requirements of the European Coil Coating Association in Brussels. PREFA guarantees the aluminium basic material for 40 years against breakage, rust and frost damage in natural environmental conditions and following installation by a professional.

Colour overview (10)

The product is available in the following colours

Colour

Code

~ RAL

01 braun

P.10 brown

7013

P.10 anthracite

7016

P.10 black

9005

P.10 brick red

8004

P.10 oxide red

3009

P.10 moss green

6005

P.10 light grey

7005

P.10 nut brown

8019

PREFA dunkelgrau ähnlich DB 703 oder RAL 7043

P.10 dark grey

7043

P.10 stone grey

7031

1 The colours P.10 stone grey, P.10 sand brown, P.10 rust brown, P.10 patina green, natural oak, grey oak, walnut, patina grey and plain aluminium reflect natural tones and are therefore subject to slight variations in colour, which give the products their unmistakable character.

3 Metallic colours may vary in shade.

Notes

  • The RAL values stated are merely approximate values (~), some of which may differ vastly from the original PREFA colour and, under certain circumstances, may not reflect the subjective perception of the colour.
  • Above all for colour quality P.10, it is almost impossible to define values due to the surface structure. Furthermore, the colours P.10 stone grey, P.10 sand brown, P.10 rust brown, P.10 patina green, natural oak, grey oak, walnut and patina grey reflect natural colourings that are composed of several colour tones.
  • To identify exact colours for complementary components please consult original samples.

Rhomboid façade tile 29 × 29 – Technical information

Material

coil-coated aluminium, 0.7 mm thick

Dimensions

437×437 mm (cover), i.e. approx. 5 pc./m²
290×290 mm (cover), i.e. 12 pc./m²

Weight

approx. 2.6 kg/m²

Supporting substrate*

on fully boarded substrate (at least 24 mm)*

* Observe country-specific standards and specialist guidelines.

Standard fastening

direct fastening, 4 PREFA ring nails per rhomboid façade tile 44×44 (i.e. 20 PREFA ring nails per m²)
indirect, 1 PREFA rhomboid façade tile clip as well as 1 ring nail per rhomboid façade tile 29×29 (i.e. 12 PREFA rhomboid façade tile clips as well as 12 ring nails per m²)

Rhomboid façade tile 29 × 29 – for wall mounting

Rhomboid façade tile 29 × 29 – for wall mounting

Rhomboid façade tile 29 × 29 – Planning and installation

More product information is available for downloading here.

Note: download DWG and DXF format files by right-clicking and selecting “Save link as”.

Rhomboid façade tile 29 × 29 – Accessories

PREFA edge cleat strip for façade shingles, rhomboid façade tiles and FX.12

1800 × 158 × 1.00 mm, pre-drilled

PREFA rhomboid façade tile clip 29 × 29

PREFA leading plate for rhomboid façade tile 29 × 29

PREFA end plate for rhomboid façade tile 29 × 29
